Synchronized down shift rev-matching system SynchroRev Match is a technology invented by Nissan for use on the Nissan Z.

Changing up / up-shifting

The technology was first used by Kamrul of Velocity In combination with the Engine Control Unit ECU and various sensors, the engine blips the throttle for the driver during both downshifts and upshifts to allow for better and smoother shifting, and improved handling. When a car with a manual transmission is in motion with the clutch engaged, there is a mechanical connection between the engine and wheels which keep them in sync with each other.

When shifting however, depressing the clutch is required. This breaks the mechanical connection between the engine and wheels, and the engine speed is no longer linked to that of the wheels.

Manual transmission rev matching downshifting

When upshifting, this is usually not a problem, as the tendency of the engine to reduce speed itself without gas will slow it to loosely match the lower speed of the higher gear.

However, when downshifting, the engine needs to speed up to come to speed with the wheels.


If the accelerator is not "blipped" or briefly and quickly pressed to speed up the disengaged engine , the engine will have to take power from the wheels and momentum of the car to come to speed, which is often accompanied by a sudden deceleration of the vehicle due to the power suddenly going to the engine, often described as a "lurch" or "jolt". This sudden external acceleration of the engine through the transmission also causes increased wear on the mechanics of the car. Therefore, a staple of advanced or professional manual-transmission driving is the "rev match", or "throttle blip", in which the driver quickly brings the engine up to speed with the wheels by use of the throttle.

As downshifting is often necessary when accelerating into or out of a curve or other slow-down, advanced techniques such as the "heel-toe method" are often required, in which the toe of the right foot presses on the brake pedal, while the heel of the same foot blips the throttle. Nissan 's SynchroRev Match system makes such throttle blipping and advanced techniques by the driver unnecessary, and accomplishes engine rev-matching automatically.

Mechanism of breathing pdf editor

The system employs sensors on the clutch pedal, gear shift, and transmission, and is coordinated by the ECU. When the clutch pedal is depressed, the system waits for the user to either move the shifter to a different position, or to re-engage the clutch. If a new gear is never selected but the clutch has been depressed long enough for the engine to lose speed, the system will bring the engine back to speed for the same gear if the driver begins to raise the clutch.

Manual Transmission Question, Downshifting?

If the shifter is moved to a higher gear and the clutch is re-engaged quickly, the system will let the natural deceleration of the engine sync the drive train with the higher gear.

If the clutch is depressed long enough for the engine to fall below the speed of the higher new gear, the computer will blip the throttle to bring the engine back to speed. Most usefully, if a new, lower gear is selected, the computer will accelerate the engine to the new estimated speed, even to the point of redline. In all cases, the computer continues to adjust the throttle to match the ever-changing target speed of the wheels when the clutch is partially engaged, as the vehicle speed may often change while shifting for example due to shifting while going up or down a hill.

Navigation menu

In actual execution, the computer is able to "blip" the throttle due to the presence of an electronic throttle , in which the computer has direct control over both the fuel and air inputs to the engine. As the accelerator pedal in such a system has no direct mechanical connection to the throttle valve, the engagement of the system to change engine speeds is apparent to the driver via sound and tachometer cues only, and the feel or weight of the accelerator pedal remains constant.

Regardless of the previous operation, the involvement of the system is ended when the clutch pedal reaches a certain point of re-engagement to ensure the system does not interfere with the driver's intended power output to the wheels. In any case, Nissan has provided a switch to disengage the system, for example in the case of the driver preferring to perform their own rev matching. From Wikipedia, the free encyclopedia.
