Do not spray insect repellent near machine. Fuel may damage surface. Wipe up spilled fuel immediately. Step A is located on the left side of tractor. Use step for entering and exiting the operator station.

John deere 4600 tractor manual library

Before starting engine to operate tractor, adjust operator seat position, height and suspension. Release lever to lock seat in position.

John deere 4600 tractor manual library

Make sure all controls can be easily accessed. Turn height adjustment knob B clockwise to raise operator seat.

John Deere 4600 Operator Manual - mattandnat.ca

Turn height adjustment knob B counterclockwise to lower operator seat. Adjust seat suspension to accommodate the weight of the operator. Operator size indications are molded into the suspension knob. Turn suspension knob C clockwise to increase seat spring tension and provide a firmer ride.

Turn seat suspension knob C counterclockwise to decrease seat spring tension and provide a softer ride. Press red button C to release seat belt allowing the belt to automatically retract.

John Deere 4500 4600 4700 Compact Utility Tractors TM1679 Technical Manual PDF

Attempting to adjust the steering wheel while the machine is moving may cause the operator to lose control of the machine. Park machine safely. Push down on lever A to lock steering wheel in position. Do not operate on roads with light switch in the field position. Rear work lights may blind or confuse operators of on-coming vehicles. C - Road Position: headlights, taillights, and warning flasher lights on.

D - Field Position: headlights, taillights, and optional working lights on.

Sharp mx 4100n user manual

A - Start Position - Rotate the key to the start position to start the engine. Release the key after the engine has started and it will automatically return to the run position. The engine will continue to run. B - Run Position - Rotate the key to the run position and the engine oil pressure light and battery charging lights should illuminate. You will also hear a clicking noise when the engine fuel shut-off solenoid engages.

John deere 4600 tractor manual library

C - Off Position - With the key in the off position, all switched power is off, and the engine should not run. There is an accessory key switch position to the left of the key switch off position. Do not move the key switch to this position. The battery could be drained. Close the valve when performing any type of engine service, during transport of the machine, and during storage.

Open or close fuel shut-off valve lever A as required:. Engine exhaust fumes contain carbon monoxide and can cause serious illness or death.

John Deere 460 Loader Off & On John Deere 4600 Tractor

Move the vehicle to an outside area before running the engine. Do not run an engine in an enclosed area without adequate ventilation.

Manuals & Training

Use the following checkout procedure to check for normal operation of tractor safety interlock system. Perform these tests in a clear open area with the machine parked on a firm, level surface. Keep bystanders away. Slowly release the clutch pedal. Raise up from operator's seat.

DO NOT dismount tractor. Engine should stop.

Training & Reference Guides

Raise up slightly off from operator's seat while depressing clutch pedal all the way down. Engine exhaust fumes can cause sickness or death. If it is necessary to run an engine in an enclosed area, remove the exhaust fumes from the area with an exhaust pipe extension.

If you do not have an exhaust pipe extension, open the doors and circulate outside air into the area. If safety interlock system is defective, engine may start.

Never stand on ground when performing tests. Perform tests in an open area away from obstructions.

JCB Manual,Tractor manual,service repair manual,workshop manual

Depress completely forward or reverse hydrostatic drive pedal. Use the hand throttle lever to set a constant engine speed for stationary operation all models or for field operation such as tillage gear transmission only.

Depress the foot throttle B to increase rpm and tractor speed. Release the foot throttle to return engine speed to the previously-set hand throttle position.

Safety & Training Videos

Using unlocked brakes to stop the machine at high speeds may cause accidental turning or tipping. Rotate brake pedal latch A clockwise until it locks into right turn brake pedal B.

Do not apply turn brakes while an attachment is engaged with the ground. Damage to the 3-point hitch and attachment may occur. NOTE: Unlocked brake pedals can be used to make tighter turns and may prevent unnecessary backing.

Lock brake pedals together when driving the vehicle to another work site or when driving on a roadway.

Emergency medicine procedures reichman pdf writer

Rotate brake pedal latch A counterclockwise until it stops against left turn brake pedal C. The brake pedals will now function independently.

Using turn brakes to stop the machine at high speeds may cause accidental turning or tipping. NOTE: Turn brake pedals can be used for tighter turns. Using turn brake pedals may also prevent unnecessary backing. Lock both brake pedals together using brake pedal lock latch A. Pull park brake lock B completely out to the locked position.

John deere 4600 tractor manual library

Remove foot from brake pedals. Both pedals should now stay down in the locked position. Push park brake lock B completely in to the unlocked position. Both pedals should now be released from the locked position. Remove foot from brake pedal. Brake pedal should now stay down in the locked position. Brake pedal should now be released from the locked position. Stop tractor motion completely and depress clutch pedal before shifting transmission gear and range shift levers.

Never rest a foot on the clutch pedal while driving the tractor. Select the proper gear and engine speed for the job. For light load operation, use higher gear and lower idle speed. For heavy load, use lower gear an higher idle speed. Gear shift lever provides three forward gears and one reverse gear. Use both the transmission gear and range shift levers in different combinations to achieve nine forward and three reverse speeds.

Depress and hold down clutch pedal C to shift the range shift lever B. Place gear shift lever A in the N neutral position. Choose A, B, or C speed range on range shift lever B to match work application:.

John deere 4600 tractor manual library

Move throttle lever all the way forward to the fast position. Stop tractor motion completely and depress clutch pedal before shifting range shift levers. The reverser lever is used to select direction of travel and N neutral.

Reverser lever must be in N neutral for the engine to start. The reverser lever can be moved to the forward or reverse position without depressing the clutch pedal. The gear shift lever provides four gear positions. Gears may be changed while tractor is in motion if clutch pedal is depressed. Release clutch gradually to take up load smoothly. NOTE: A low speed creeper gear is available as an option, providing a fourth speed range.

The range shift lever provides three speed ranges. Stop tractor and depress clutch pedal before changing speed ranges. Using both the transmission gear and range shift levers in different combinations, twelve forward and twelve reverse speeds can be achieved.

Panasonic bread machine recipe book

Depress and hold down clutch pedal D to shift the range shift lever C. Place gear shift lever B in the N neutral position. Choose a speed range on range shift lever C to match work application:.
